| インターフェイス標準: | タイプ-1/タイプ-2/GB/T | 出力電力: | 7 kW |
|---|---|---|---|
| 入力電圧: | 200 - 220v | 入力頻度: | 50Hz+-3％または60 Hz+-3％ |
| 接続性: | WIFI/Bluetooth/4G | ユーザーインターフェイス: | 3.8インチLCDまたはLED |
| 通信プロトコル: | 独自およびOCPP 1.6j/2.0.1 | RFIDの読者: | ISO/IEC 14443 A/B MIFARE RFIDリーダー |
| 保護評価: | IP55 | 動作温度: | -35°C〜 +50°C |
| サイズ: | 202*104*388mm | 重さ: | 6kg（列なし） |
| 出力電圧: | AC 220V±20% | 出力電流: | 各フェーズ0-32a |
| ストックワイヤの長さ: | 5m （カスタマイズ可能） | ||
| ハイライト: | 7kW EV charging station with WiFi,Type 2 plug EV charger,AC EV charger with warranty |
||
| Item | Specification |
|---|---|
| Installation Method | Wall-mounted, column (optional) |
| Rated Power | 7KW, 11KW, 22KW |
| Charging mode | APP(QRCode), Plug & Charge, RFID |
| Size (H * W * D) | 202*104*388mm |
| Weight | 6kg (Without column) |
| Input | |
| Input voltage | 230VAC/400 VAC/400 VAC |
| Input Current | Each phase 0~32A |
| Leakage Protection | Overcurrent, overvoltage, undervoltage, ground fault, integrated surge protection, RDC (typeA + DC6mA), over-temperature protection |
| Output | |
| Output voltage | AC 220V±20% |
| Output current | Each phase 0-32A |
| Connection method | |
| Number of plug | 1 |
| Charging connection method | 1. Connection method C (plug version) 2. Connection method B (socket version) |
| Plug wire length | 5m (customizable) |
| Plug standard | Type-1/Type-2/GB/T |
| Human-computer interaction | |
| LED | LED Status light |
| Other | |
| Protection level | IP55 |
| Operating temperature | -35°C to +50°C |
| Relative humidity | <95%, No condensation |
| Lifespan | ≥10000 times |
